Midwest Motion Products Inc., with Manufacturing and Office Facilities now based in Howard Lake, Minnesota, is pleased to announce the release of the new "TM57-GRA52" Right Angled Gearmotor System.
This new 1:1 Right Angled Gearbox allows for significantly increased versatility, and design whose geometry allows for the unit to be mounted in tight spaces.
High resolution. Limited space. Not a problem for our latest miniature encoders that provides precise feedback and is easy to install within smaller-sized applications. Now available in 400 and 500 CPRs. Coming in at about the size of a nickel, we've added our proprietary Opto-ASIC sensor technology and improved quadrature for even greater motion control.
Product Features: 10 resolutions up to 360 CPR, plus new 400 and 500 CPR resolution; 288 configurations available, including single and differential output; Compact form factor
• 0.866 inch (in) / 22.00 millimeter (mm) package outside diameter
• 0.446 in / 11.33 mm package height
• Fits NEMA 8, 11, 14 and 17 motors;
Simple and efficient assembly process
• Four-piece construction
• Push-on hub disk design, patent pending;
100 kilohertz frequency response;
Shafted version up to 0.25 in / 6.25 mm diameter.
